Input Power: AC 110V/220V ±10% 50Hz/60Hz
Resolution: AD：16bit；DA：16bit
Input Resistance: ≥10 GΩ
Input Power: 354mW
Channel Features: Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure
Channel Control Mode: Independent Control
Voltage
Constant Voltage Range: 25mV~5V
Discharge Min Voltage: 0V
Accuracy: ± 0.05% of FS
Stability: ± 0.05% of FS
Current
Per Channel Current Range: 0.025mA-5mA
Accuracy: ± 0.05% of FS
Stability: ± 0.05% of FS
Power
Per Channel Output Power: 0.025W
Stability: ± 0.1% of FS
Time
Current Response Time: 1ms (0-Full Range)
Step Time Range: ≤(365*24 )hour/step，Time Form Support 00：00：00(h、min:s、ms)
Data Recording
Record Condition
Minimum Time Interval: 100ms
Minimum Voltage Interval: 10mV
Minimum Current Interval : 0.01mA
Record Frequency: 10Hz
Charge Charge Mode: Constant Current Charge, Constant Voltage Charge, Constant Current and Constant Voltage Charge, CPC
End Conditon: Voltage, Current, Relative Time, Capacity
Discharge
Discharge Mode: CCD、CPD、CRD
End Condition: Voltage、Current、Relative Time、Capacity、
Pulse
Charge: CCC, CPC
Discharge: CCD, CPC
Min Pulse Width: 500ms
Automated Switch: Automated swith from charge to discharge for each pulse
End Condition: Voltage, Test Time
Cycle
Loop Measure Range: 1~65535 times
Max Steps Per Loop: 254
Nested Loop: Nested loop Function，Max Support 3 Layers
Protection
Software Protection
Power-down Data Protection
Off-line Testing Function
Setting Protection Condition，Setting Parameter：Low Voltage limit、Upper Voltage limit、Low Current limit、Upper Current limit、Delay Time
Hardware Protection: Additional Anti-reverse Protection Model
DCIR testing: Support
Voltage and Current Testing Sample: 4-wire connecting
Noise: <85dB
Database: MySQL Database
A Means of Communication of Upper Machine: TCP/IP Protocol
Data Output: EXCEL、TXT、Graph
Communication Interface: Ethernet Port
Per Unit Main Channels No.: 8
Dimensions: 250*200*60(mm)
