Volume, size and weight
Inner volume: 25L
Inner box size: W280 mm×D250 mm×H360 mm
Appearance size: W360 mm×D450 mm×H470 mm
Net weight of equipment: About 40kg
Performance
Test environmental conditions: Environmental temperature+25℃、Relative humidity≤85%、No sample in the test chamber (no load)
Temperature range: 15～60℃
Temperature fluctuation: ≤1℃（No load, stable temperature）
Temperature deviation: ±2.0℃（No load, stable temperature）
Heating time: 25℃→60℃ ≤30 min
Cooling time: 25℃→15℃ ≤60 min
Electrical control system
Controller: LED Digital display + touch key controller
Setting method: Touch key
Control way: Forced circulation ventilation. The control system controls the output of the semiconductor cooling (heating) module according to the set temperature value and automatically calculates the output result through PID, so as to achieve dynamic balance.
Communication way: Ethernet standard interface
Power cord
Plug wire: 1.5m 10A three-hole plug cable (with leakage protection)
Environmental conditions: Temperature：5℃～35℃；Relative humidity：≤85%；Air pressure：86kPa～106kPa
Power supply condition
Voltage: AC(220±22)V (50±0.5)Hz
Power: Single phase + protection ground wire 0.2kW
Maximum current: 1A
