Grinding tank volume: 100ml*4
Grinding tank material: Zirconia, corundum, agate, cemented carbide, stainless steel, PTFE, PU, nylon.
According to your needs.
Grinding ball material: Matching grinding ball (large, medium and small size)
Max loading volume: Material and grinding balls no more 1/3 of volume
Feeding material size: Soil material ≤ 10 mm, other materials ≤ 3 mm
Output material size: Min 0.1um
Speed: Revolution 45-435 r/min, Rotation 90-870 r/min
Speed mode: Stepless speed regulation, automatic timing forward and reverse, automatic shutdown.
Working Voltage: AC 220V
Motor frequency conversion controller power: 0.25kw
Max continuous working time: 72hours
Dimension: 500*300*340mm
Weight: About 30kg
Datasheet
Remark
The ball mill is controlled by a high-tech microcomputer chip. It can be set to forward, reverse alternately run (0-999min), and forward, pause, reverse, pause, forward alternately run (0 999min), especially suitable for cooling or intermittent operation.
It can be used for dry grinding and wet grinding. It can be equipped with vacuum filling inert gas grinding or low temperature grinding.
Grease lubrication is adopted at the gear transmission to reduce the running noise of the equipment.
