Measuring Parameters: DC resistance
Resistance Test Range: 10μΩ — 200kΩ
Basic Resistance Test Accuracy: 0.05%
Resistance Range: Auto and manual (200mΩ, 2Ω, 20Ω, 200Ω, 2kΩ, 20kΩ, 200kΩ)
Measurement Mode: Stand-alone, scanning
Scanning Channels: 15 channels/boards, and up to 6 boards and 90 channels can be inserted.
Test Terminal Selection of Test Channel: Arbitrary configuration between channels (programmable)
Test Current: ≤100mA
Measurement Speed: single board: 100 times / sec, 40 times / sec, 2 times / sec, 6 boards: 600 times / sec, 240 times / sec, 12 times / sec
Display Results: Simultaneous display the test results of 16 channels and support page turning
Short-circuit Clear Correction: Support full-scale short-circuit clearing for all channels
Comparators: Comparison boundaries are set separately for each test channel
Limit Mode: ABSDev、ABS、%
Trigger Mode: Auto trigger, manual trigger, bus trigger, Handler trigger, foot switch trigger
Test Terminal: Four-terminal test
Storage: 30 sets of instrument parameters
