Display: 800×RGB×480 7-inch TFT LCD display
Frequency of test signal: 20Hz—500kHz
Minimum resolution: 1mHz, 5-digit frequency input
Accuracy: 0.01%
Test parameters of LCR: |Z|, |Y|, C, L, X, B, R, G, D, Q, θ, DCR, Vdc-Idc
Basic accuracy: LCR test parameter: 0.05%
Measurement time (≥10 kHz):
- Fast: 9 ms / time
- Medium: 67 ms / time
- Slow:187 ms / time
- Plus the refresh time of display character
Display range of LCR parameter:
- |Z|, R, X, DCR: 0.00001Ω — 99.9999MΩ
- |Y|, G, B: 0.00001μs — 99.9999s
- C: 0.00001pF — 9.99999F
- L: 0.00001μH — 99.9999kH
- D: 0.00001 — 9.99999
- Q: 0.00001 — 99999.9
- θ(DEG): -179.999º — 179.999º
- θ(RAD): -3.14159 — 3.14159
- Δ%: -999.999% — 999.999%
Operating temperature and humidity: 0℃－40℃, ≤ 90%RH
Power supply:
- Voltage: 99V－121V，198V－242V AC
- Frequency: 47Hz－63Hz
Consumption: Max. 80 VA
Dimension(W×H×D): 400mm × 132mm × 385mm
Weight: Approx.13 kg
