Display
+ Display: 10.1" Captive Touch Screen
+ Ratio: 16:09
+ Resolution: 1280×RGB×800
Frequency
+ Range: 20Hz-500kHz
+ Accuracy: 0.01%
+ Resolution: 0.1mHz (20.0000Hz-99.9999Hz)-10Hz (1.00000MHz-2.00000MHz)
Test Level
+ AC Voltage: 5mVrms-20Vrms
+ Accuracy: ±(10%×the set value+2mV)(AC<=2Vrms)
±(10%×the set value+5mV)(AC＞2Vrms)
+ Resolution: 1mVrms (5mVrms-0.2Vrms)-10mVrms (10Vrms-20Vrms)
+ AC Current: 50μArms-100mArms
+ Resolution(100Ω Internal Resistance): 10μArms (50μArms-2mArms) - 100μArms (50mArms-100mArms)
RDC Test
+ Voltage: 100mV-20V
+ Resolution: 1mV (0V-1V) 10mV (1V-20V)
+ Current: 0mA-100mA
+ Resolution: 10μA (0mA-10mA)
100μA (10mA-100mA)
DC Bias *
+ Voltage: 0V-±40V
+ Accuracy: AC<=2V 1%×the set voltage+5mV
AC>2V 2%×the set voltage+8mV
+ Resolution: 1mV (0V - ±1V); 10mV (±1V - ±40V)
+ Current: 0mA-±100mA
+ Resolution: 10μA (0mA-10mA); 100μA (10mA-100mA)
Measurement display range
Cs, Cp: 0.00001pF-9.99999F
Ls, Lp: 0.00001μH-99.9999kH
D: 0.00001-9.99999
Q: 0.00001-99999.9
R, Rs, Rp, X, Z, RDC: 0.001mΩ-99.9999MΩ
G, B, Y: 0.00001μs-99.9999S
VDC: ±0V-±999.999V
IDC: ±0A-±999.999A
θr: -6.28318
θd: -179.999°-179.999°
Δ%: ±(0.000%-999.9%)
Size (WxHxD): 430mm(W)x177mm(H)x405mm(D)
Weight (kg): 17kg
