Maximum force capacity: 15000kg (150KN) load cell for push and pull, 0.4%~100%
Force measurement accuracy: within 0.5%
Test stroke: 800mm, effective test width: 400 mm, or specified per customer
Test force loading the measuring range: 0.4%-100%FS
Resolution: maximum test force of 1/200000
Test speed: 0.01 - 500mm/min. or specified per customer.
Displacement measurement accuracy: ±0.5% of indication
Test force control rate adjustment range: 0.05%-5% FS/S
Control accuracy: ± 0.5% when the control rate ≥0.05% FS/S
Machine size: 1100*700*2100mm(L*W*H)
Dynamic system: servo motor + high precision ball screw
Power: 220V/50HZ, 4.4KW
Accessories: 1 no Load cell, standard grips, operation software, English manual books and Video
Net Weight: 520kg, Gross weight:600 kg (after wooden package)
Package of strong wooden box size: 118cm*80cm*230cm
