Frequency range： 300kHz ～ 4.5GHz
● Number of test ports： 2-port basic unit (2~10 ports to
be selected arbitrarily)
● Dynamic range： >120dB（ IFBW 10Hz） typ. 123dB
● Power range： -50~+10dBm
● Power accuracy： ±1.0dBm
● IF bandwidths： 10Hz~100kHz
● Trace noise： 0.002dBrms
● ●
Up to 128 traces and channel
● It supports standard VISA remote control command and
is compatible with test cases of products of the similar
type
Frequency range 300kHz ~ 4.5GHz
Impedance 50Ω、 75Ω1
Test port connector N-Type, Female
Number of test 1 ~ 10
IF bandwidth 10Hz ~ 100kHz
Dynamic range
IFBW 3kHz:
300kHz ~ 10MHz : 80dB; 10MHz ~ 4.5GHz : 95dB
IFBW 10Hz:
300kHz ~ 10MHz : 105dB; 10MHz ~ 4.5GHz : 123dB
Frequency accuracy 5.0 ppm
