Weight: 287 g (incl. batteries)
Dimensions (length x width x height): 217 x 80 x 38 mm
Max. diameter of conductor approx. 28 mm
Display: LSC (2000 counts)
Measuring rate: 2 per second
Input resistance (V AC and V DC): 10 MΩ
Max. input value alternating current: 400 A
Max. input value voltage (AC and DC): 600 V AC/DC
Max. input value resistance; diode; continuity: 250 V AC/DC
Frequency range alternating current: 50/60 Hz (AAC)
Frequency range AC voltage: 50–400 Hz (VAC)
Ambient conditions: 5°C to 40°C (41°F to 104°F)
Storage conditions: -20°C to 60°C (-4°F to 140°F)
Relative humidity: max. 80 % RH at 31 °C (87 °F). decreasing linearly up to 50 % RH at 40 °C (104 °F)
Type of protection: IP20
Batteries: 2 x 1.5 V AAA
Overvoltage protection: Category lll 600 V
Automatic switch-off: after 15 minutes
Measuring range
AC voltage (V/AC): 2 V~600 V
DC voltage (V/DC): 200 mV~ 600V
Alternating current (A/AC): 2 A~400A
Resistance(Ω): 200 Ω~ 20 MΩ
Function:
+ Diode measurement: Test voltage: approx. 2.5 V; Test current: approx. 0.6 mA
+ Continuity check: Acoustic signal at ≤ 100 Ω; Acoustic signal possible at 20 Ω – 150 Ω; No acoustic signal at > 150 Ω
Scope of delivery
• 1 x device
• 1 x Red measuring cable
• 1 x Black measuring cable
• 3 x 1.5 V battery AAA
• 1 x manual
