- Voltage Measurement
Nominal input voltage ( kV ): 20
Maximum input voltage ( kV ): 22
Nominal output voltage ( V ): 10
Proportional uncertainty ( k=2, ppm ): 50
- Auxiliary Performance
Input resistance ( MΩ ): 400
Output resistance ( kΩ ): 200
Temperature coefficient ( ppm/K ): 5
Voltage influence factor ( ppb/V ): 1
- General Specifications
Power supply: ——
Warm up time: 30 minutes
Temperature performance: Operating temperature: 5°C ~ 40°C; Storage temperature: -10°C to 55°C
Note: When stored in a harsh temperature environment, the resistance value may change temporarily and be restored to the original resistance value within the following 30 days.
Humidity performance:
Working humidity :(30%-70%) R·H, no condensation
Storage humidity :(20%-80%) R·H, no condensation
Connection mode: The input connection adopts high pressure socket, and the output connection adopts a pair of ф 4 mm female socket.
Size (mm) (W * D * H) (excluding terminals): 430x320x250
Weight ( kg ): 13.5
