Insulation Resistance Measurement
500V
0.50MΩ~4.99G±(5%+5)
5.00G-49.9GΩ±(10%+10)
50.0GΩ-500GΩfor reference only
1000V
1.00MΩ-9.99GΩ±(5%+5)
10.0G-99.9GΩ±(15%+10)
100GΩ-1000GΩfor reference only
2500V
2.50MΩ-24.9GΩ±(5%+5)
25.0G-249GΩ±(15%+10)
250GΩ-2.5TΩfor reference only
5000V
5.00MΩ-49.9GΩ±(5%+5)
50G-499GΩ±(15%+20)
500GΩ-5.0TΩfor reference only
10000V
10.0MΩ-99.9GΩ±(10%+10)
100G-999GΩ±(20%+20)
1000GΩ-10TΩfor reference only
12000V
12.0MΩ-99.9GΩ±(10%+10)
100G-999GΩ±(20%+20)
1000GΩ-10TΩfor reference only
Output voltage
500V0~+10%
1000V0~+10%
2500V0~+10%
5000V0~+10%
10000V-5~+10%
12000V-5~+10%
Load current
500V (R=500KΩ) 1mA 0%---+20%
1000V (R=1MΩ) 1mA 0%---+20%
2500V (R=2.5MΩ) 1mA 0%---+20%
5000V (R=5MΩ) 1mA 0%---+20%
10000V (R=10MΩ) 0.15~1.2mA 0%---+20%
12000V (R=12MΩ) 0.15~1.2mA0%---+20%
DC voltage measurement: 30V~1000V/±(3%+5)
AC voltage measurement: 30V~750V (50~60Hz) /±(3%+5)
Features
PC software for data analysis: √
Backlight Function: √
Date storage999 sets of date:√
Dielectric Absorption Ratio (DAR) :0.00~999√
Polarization Index (PI)0.00~999:√
General Characterisitics:
Power:1.5V alkaline batteries (LR14) X 10, power adapter
Product color:Red and grey
Product net weight:6.6kg
Product size:410*342*204mm
Standard accessories: User manual, Test leads (red/black/green 1 each), USB cable, power adaptor, 1.5V alkaline batteries
