Main board: DC 9 - 60 V
Display board: Single
Output: None
Input: 1 to 5 V, 4 to 20 mA
Display:
Main display Red LED 14.2 mm height
Sub display Green LED 8 mm height
Conversion rate: 12.5 times/sec.
Maximum display: 9999
Overrange indication: When input exceeds the maximum display, display OL or –OL
Zero display: Leading zero suppression
Decimal point: Settable to any digit position
External control: Start/Hold, Peak Hold, Digital Zero
Operating temp.: 0 to 50°C 35 to 85% RH
Storage temp.: –10 to 70°C less than 60% RH
Power supply:
AC 100 to 240V±10% (AC main unit)
DC 9 to 60 V (DC main unit)
Power consumption: approx 4 VA (at 100 V)
Dimensions: 96 mm (W) X 48 mm (H) X 147.5 mm (D) DIN size
Weight: approx. 450 g
