Max.drilling capacity (mm): 31.5
Max.Tapping capacity (mm): cast 20 steel 16
Distance spindle axis to column generating line (mm): 300-700
Diameter of column (mm): 150
Spindle taper: MT3
Spindle travel (mm): 130
Spindle speeds range (r/min): 100-1600
Spindle speeds series: 8
Range of Spindle feeds (mm/r): 0.08 0.14 0.23
Rotary angle of rocker in horizontal plane (°): 360
Distance spindle nose to working surface of base (mm): 275-680
Dimension of worktable (mm): 250X250X250
Dimension of base (mm): 1200X625X155
Overall size (mm): 1235X625X1230
Power of Main motor (w): 750
G.W/NW (kg): 540/500
Packing dimension (cm): 127X69X137
