Max.drilling capacity (mm): 40
Distance spindle axis to column generating line (mm): 300-1000
Diameter of column (mm): 240
Spindle taper: MT4
Spindle travel (mm): 280
Spindle speeds range (r/min): 32-2500
Spindle speeds series: 16
Range of Spindle feeds (mm/r): 0.10-1.25
Mpindle Spindle feeds: 8
Distance spindle nose to working surface of base (mm): 220-1000
Dimension of worktable (mm): 600X450X450
Dimension of base (mm): 1710X800X160
Overall size (mm): 1760X800X2050
Power of Main motor (kw): 2.2
G.W/NW (kg): 1920/1830
Packing dimension (cm): 187X97X220
