Drilling capacity: Ø63mm
Tapping capacity: M36
Motor power: 5.5kW
Spindle Type: MT5
Spindle stroke (drill head): 400mm
Cross stroke: 1600mm
Speed: 20-1600 rpm
Speed Levels: 16 levels
Spindle feeds: 0.04 - 3.2mm/r
Working table dimension: 950x630x500mm
Column diameter: 450mm
Distance from spindle to base: 450-2050mm
Maximum distance from spindle center to column: 2050mm
Minimum distance from spindle center to column: 450mm
Base dimension: 2900x1250x250mm
Machine dimension: 3110x1250x3150mm
Packing dimension: 3480x1470x2210mm
Weight: 6795/7145kg
