Input frequency range: 20 - 3000 MHz
Tuning resolution: 10 Hz
Output frequency: 21.4 MHz
Output bandwidth: 22 MHz
Gain: 30 dB typ.
Noise figure: 12 dB typ. @ 100 MHz
Internal spurii: -105 dBm typ.*
IF rejection: >60 dB
Maximum input level: +10 dBm
Attenuation control: 0-30 dB switchable front-end attentuator in 2 dB steps, 20 dB switchable attenuator in IF path
IP3: 0 dBm typ.
Input impedance: 50 ohm (SMA connector) for each channel
Output impedance: 50 ohm (SMA connector) for each channel
Amplitude ripple: 3 dB typ.
Phase ripple: 3 degrees typ.
Phase adjustment range: 20 degrees typ.
Phase adjustment resolution: 0.1 degrees typ.
Channel-to-channel isolation: >80 dB
Operating voltage: 12 V DC ±5%
Power consumption: 8 W typ.
Dimensions: 150 x 90 x 30 mm (5.9" x 3.5" x 1.2")
Weight: 330 g (11.6 oz)
Operating temperature: -10º to +60º C
Humidity: 20-90% non-condensing
