Max. drilling diameter: 50mm
Distance between spindle axis and column: 350-1600mm
Distance spindle nose and work surface of base: 320-1220mm
Rocker arm lifting distance: 580mm
Rocker arm lifting speed: 0.02m/s
Spindle travel: 315mm
Spindle taper: 5 Morse
Range of spindle speeds: 25-2000 r/min
Number of spindle speeds: 16 step
Range of spindle feeds: 0.04-3.20mm/r
Number of spindle feeds: 16 step
The maximum torque of the spindle: 500 N.M
Spindle maximum feed resistance: 18000N
Table size: 630×500mm
The spindle box of horizontal moving distance: 1250mm
Spindle motor power:4kW
Hydraulic clamping motor power: 0.75kW
Cooling pump motor power: 0.09kW
Arm lift motor power: 1.5kW
Machine weight: 3500kg
Overall dimension: 2500×1070×2840mm
