Max. drilling diameter (on Medium-carbon steel): φ62
Max. drilling diameter( on cast iron): φ72
Max. tapping diameter (on Medium-carbon steel): M46
Max. tapping diameter (on cast iron): M52
Max.Distance from spindle to generating line of column: 350-1600
Distance of horizontal movement for spindle box(manual): 1250
Max. distance between spindle end to the worktable surface of the base: 350-1250
Max. travel of the spindle: 315
Spindle taper bore: MT.5
Spindle speed steps: Stepless
Spindle speed range: 38-275; 275-2000
Spindle feed steps: 8
Spindle feed range: 0.06-1.00
Speed of rocker arm up and down movement: 1.2
Rotation angle of rocker arm.: ±180
Distance of spindle movement for calibrated dial each revolution: 122
Power of main motor(tranducer motor): 4
Power of motor for rocker arm up and down movement: 1.5
Power of oil pump motor for spindle box, column and rocker arm clamping: 0.75
Weight of machine(without worktable): 3800
Machine dimension (L x W x H): 2490×1000×2598
