DC voltage measurement
Rated total voltages: 24V/48V/110V/220V
Discharge ranges:
10V-30V; 55A
30V-150V; 110A
150V-300V; 55A
Accuracy & resolution: ±0.3% FS +0.3V; 0.1 V
DC voltage measurement
Internal current range: Max 110A at 1-110A adjustable
Accuracy & resolution: ±0.5% FS +0.6A; 0.1 A
Cell voltage type: 1.2V/2V/4V/6V/12V
Accuracy & resolution: ≤ ± 0.5%; 0.01 V
Power supply
Power supply: 220V AC (-20% to +20%) 50Hz/60Hz
Cooling mode: Forced air cooling
Communication & storage
Storage mode: USB internal storage
Internal memory: 16MB flash or optional
Display: 7inch touch screen
HV insulation test:
Input-The enclosure: 2200Vdc 1min
Input-Output: 2200Vdc 1min
Output-The enclosure: 700Vdc 1min
Environment
Work temperature: -5～50℃
Storage temperature: -40～70℃
Humidity : 5%～95% RH
Altitude below: 4000 m
Working noise: <60 dB
Dimensions of host machine: 800 x 290 x 540 mm
Dimensions of package : 960 x 530 x 850 mm
Net weight: 50kg
