Wrindu RDFJ-708B SF6 Decomposition Products Tester (0 ～ 100μL/L)

Measuring range:

- SO2：0 ～ 100μL/L

- H2S：0 ～ 100μL/L

- CO: 0 ～ 1000μL/L

- HF: 0 ～ 10μL/L

Measuring accuracy:

- SO2：when the measured value ≤10μL/L， the error±0.2μL/L;

when the measured value≥10μL/L， the error≤±3%

- H2S：when the measured value≤10μL/L， the error±0.2μL/L;

when the measured value≥10μL/L， the error≤±3%

- CO: when the measured value≤50μL/L， the error±0.5μL/L;

when the measured value≥50μL/L， the error≤±4%

- HF: the error of measured value≤±0.1μL /L

Repeatablity:

- SO2：when the measured value≤10μL/L，the repeatablity≤±0.1;

when the measured value≥10μL/L,the repeatablity≤±2%

- H2S：when the measured value≤10μL/L,the repeatablity≤±0.1;

when the measured value≥10μL/L,the repeatablity≤±2%

- CO: when the measured value≤50μL/L,the repeatablity±0.3;

when the measured value≥50μL/L,the repeatablity≤±3%

- HF: the repeatability of measured value≤±0.1

Resolution: 0.1μL/L

Sampling flow: 0.2L/min

Measuring time: ≤180S

Working environment: Temperature-10℃ ～ +50℃,Humidity0 ～ 90%RH

Supply power: Lithium battery power supply, AC and DC dual-use, automatic switching, overcharge and over discharge protection function

Dimension: 330(mm)×220(mm)×150(mm)；

Weight: 4.8KG

Product features:

1. Long life detection components

2. Direct measurement without colorimetric tube or sensor

3. High accuracy and good repeatability

4. Built-in pressure regulator and electronic mass flow meter

5. Large color LCD display

6. Lithium battery power supply, AC and DC dual-use

7. The Sf6 Comprehensive Analyzer comes with cleaning function
