Rated output voltage: 0~50kV(AC RMS)
Output frequency: 45~65Hz
Resonance voltage waveform: Pure sine wave, waveform distortion rate≤1.0%
Work system: Under full power output, normally continuous work time5min
Quality factor: 10~40
Frequency regulation sensitivity: 0.1Hz, Instability <0.05%
Maximum test capacity: 5000kVA and below
Working power supply: 220V and 380V±10%, Power frequency 50Hz±5%
Control console: 25kW/380V
Reactor: 50kV/1.5A Two.50kV/1.5A
Excitation transformer: 25kW/5kV
Voltage divider: 50kV/500pF
Applicable objects: generator 0.2~0.27uF.10kV cable(300mm2)≤2.5km
