System (Upper Chamber): Natural convection, Air jacket
Operating Temp. Range(Upper Chamber): Room temp.＋5℃～80℃
Temp. Adjustment Accuracy (Upper Chamber): ±0.5℃（at 37℃）
Temp. Distribution Accuracy (Upper Chamber): ±1.0℃（at 37℃）
Cable Port (Upper Chamber): 30mm ID (Right side from the front)
Exhaust Port (Upper Chamber): 30mm（with Damper）, 2 ports on the top
Internal Dimensions (Upper Chamber): 600×530×500mm
Internal Capacity (Upper Chamber): 150L
System (Lower Chmber): Forced convection
Operating Temp. Range(Lower Chamber): +4℃～50℃
Temp. Adjustment Accuracy (Lower Chamber): ±0.3℃（at continuous refrigeration）
Temp. Distribution Accuracy (Lower Chamber): ±1.0℃（at continuous refrigeration）
Refrigerator (Lower Chamber): Air cooling, 250W
Refrigerant (Lower Chamber): R404A
Interior (Lower Chamber): 600×477×500mm
Internal Capacity: 143L
Sensor: Pt100Ω
External dimensions（W×D×H mm）: 710×656×1792mm
Remarks(dimensions): 150L (Upper chamber ) + 143L (Lower chamber)
Power Source: AC220V 7A Single-phase with step-down transformer
Weight: 160kg
