Chamber: 1,000 × 555 × 900 mm(Volume Approx. 0.5 m3)
Specimen: L125 ± 5 mm, W13.0 ± 0.5 mm, T13 mm or less
Burner: L100 ± 10 mm, Inner Diameter φ9.5 ± 0.3 mm
Burner Base: Slide type (With Operation Handle), Inclination Angle 45 ± 2°, 20 ± 5° (5 V)
Burner Calibration Device:
+Flow Meter: Max.150 ml/min (Scale 2 ml/min) (Standard 105 ml/min)
+Flow Meter: Max. 1,000 ml/min (Scale 10 ml/min) (Standard 965 ml/min)
+Manometer: Max. 200 (± 100) mmH2O (Scale 1 mmH2O) (Standard 10 mmH2O)
+Timer, Built-In Thermometer
Accessories: Flame Gauge (20 mm) (Option: 125 mm & 38 mm), Ring Stand,Wire Mesh, Dry Cotton Pad, Fireproof Gloves, Gas Lighter
Option: Horizontal Burning Support Fixture (HB),Plaque Support Fixture (5 V), Spring Clamp (VTM), Foam Support Fixture
Power Source: AC 100 V, 1-Phase, 15 A, 50/60 Hz
Heat Source: Methane Gas (Purity: 98 % Over)
Dimensions/ Weight (Approx.): W1,510 × D610 × H1,100 mm 200 kg
