AC current: 400/600A; 1.5+5 (50/60Hz)
DC current: 400/1000A; 1.0+5
AC voltage: 40/400/600V; 1.5+5 (50/60Hz)
DC voltage: 40/400/600V; 1.0+5
Crest factor: accuracy 3
Resistance: 400/4000Ω; 1.0+5, Beeps at below 20Ω(continuity check)
Frequency: 10～3000Hz; 1.5+5
Method of detection: True RMS
Display: LCD(Digital display:3999 counts)
Response time: Approx. 2 seconds
Range switching: auto-range
Data hold: On all range
Peak hold: On AC/DC current range, AC/DC voltage range
Operating temperat ure and humidity : 0-40;, 90% RH or less (no condensation)
Effect of conductor position: 2% or less
Safety standard: Conforms EN61010-1, EN61010-2-031, EN61010-2-032
Circuit voltage: 600Vrms or less
Withstanding voltage: 6300V AC for 5 sec
Power supply: 6F22(006P)9Vx1 or 6LR61x1
Batttery life: Approx. 15 hours (continuous)
Consumed current: Approx. 15mA
Sleep function: Automatically powered down in about 30 minutes after the last switch operation
Diameter of measurable conductor: 33mm at maximum
Dimensions: Appro. 91(W)x210(H)x40(D)mm
Weight: Approx. 450g
Accessories: User's manual, batteries, carrying case(93032), Test Lead (98071)
