Capacity (optional): 100N, 250N, 500N, 1KN, 2.5KN, 5KN, 10kN, 15kN, 20KN, 30KN
Unit (Switchable): N,KN,kgf,Lbf,MPa,Lbf/In,kgf/mm
Precision Grade of Machine:0.5 Level/1 Level
Load Resolution: 1/500,000 (0.5 Level)/ 1/250,000 (1 Level)
Load Magnifying Rate: Section-less
Max Stroke (Exclude the Grips): 650 mm (Standard) 850 mm (Heighten)(Optional)
Effective Width: 400 mm,others(Customized)
Test Speed: 0.001-500 mm/min or others
Speed Accuracy: ±0.5%
Displacement Resolution: 0.0004mm
Software: Spring test special software
Motor: Servo motor
Transmission Rod: High accuracy of ball screw
Main Unit Dimension(WxDxH): Standard: 585x505x1290 mm
Power: AC220/50Hz 10A or specified by user
