GlobeCore UOV Compressed Air Supply Unit (0.7 MPa (psi); 5.5 kW)
Manufacturer: GlobeCore Model: UOV - Contact
Operating pressure, MPa (psi): 0.7 (101.5)
Compressed air temperature range, 0С (0F): +5…+40 (+41…+104)
Operation mode: Continuous (duty ratio=100%)
Residual content of oil in the air, max, g/m3 (lb/gal): 0.001 (8.34⋅10^-9)
Simultaneous hose connections: 2
Max power requirement, kW: 5.5
Three phase 50 Hz AC voltage: Customizable
Compressor assemble air tank volume, liters (gal): 270 (71)
Dew point, 0С (0F): -70 (-94)
Dimensions, mm (in) max:
– length: 3910 (154)
– width: 1950 (77)
– height: 2150 (85)
Weight, kg (lbs) max: 1200 (2645)
