Power Supply: 230VAC ±10%, 50-60Hz +/- 1Hz
Battery: 6 x 1.5V AA (batteries not included)
Dimensions (L x W x H): approx. 270 x 110 x 75 mm
Weight: 1.6 kg / 3.5 lbs including batteries
Protection Class: IP40
Standards: IEC/EN 62353, NFPA-99, AS/NZS 3551
Measurement Functions:
Earth Bond Resistance: >200 mA DC test current
Insulation Resistance: 50 / 100 / 250 / 500 V DC
Leakage Current: 4 µA – 9999 µA
Voltage Measurement: up to 300 V AC
Measurement Capability: Battery-powered insulation & earth bond testing
Features:
Test Modes: Automatic, semi-automatic, manual
Test Sequences: Fully customizable
Data Storage: Internal memory with onboard data logging
Data Management: PC communication & download
Operation: No mains required for many tests → full portability
Verification: Automatic secondary check for correct results
