Application: Standards-compliant testing of electrical medical equipment, including production testing
High-Voltage Test: up to 6 kV DC
Protective Conductor Test: 200 mA AC/DC, 25 A AC
Display: 4.3” TFT color touchscreen
Data Memory: up to 50,000 objects
Interfaces: USB
Measurement Category: 300 V CAT II
Protection Class: Class I (EN 61140)
Measurement Functions:
Protective Conductor Resistance: Yes (200 mA / 25 A)
Insulation Resistance: Yes
Leakage Current: PE, touch, device, patient, applied part
Measurement Methods: Direct, differential, equivalent leakage
Voltage Measurement: SELV, PELV
PRCD Test: Tripping time
Functional Test: U, I, P, S, frequency
Line Test: Continuity, short circuit, polarity
Features:
High-Voltage Testing: Integrated (production use)
Test Sequences: Preconfigured & automatic
User Guidance: Automated workflow
Terminals: 10 configurable 4 mm ports for applied parts
Remote Control: Via PC (IZYTRONIQ)
Database: Expandable (DB+)
Special Feature: Antimicrobial housing
