Width: 72 mm
Height: 35 mm
Length: 123 mm
Mounting: DIN-Rail or Wall Mount
Bandwidth: 500 Hz
Isolation: Input to Output Isolation: 3750 Vrms, Ethernet Isolation: 1500 Vdc
Input Type: N/A
Switch Type: SPST NO
Release Time: 3 ms
Digital Input: N/A
Output Signal: Power Relay
Data Interface: Ethernet
LED Indicators: L1 (System Running): Yes, L2 (Ethernet Link/Act): Yes, L3 (Ethernet 10/100 M Speed): Yes
Supply Voltage: 10 to 30 Vdc
Channel Current: 5.0A/channel at 25°C
Electrical Life: VDE: 5 A @ 250 Vdc 30,000 ops (10 ops/minute) at 75°C, 5 A @ 30 Vdc 70,000 ops (10 ops/minute) at 75°C; UL: 5 A @ 250 Vac/30 Vdc 6000 ops, 3 A @ 250 Vac/30 Vdc 100,000 ops
Impedance Input: 10 kΩ
Mechanical Life: >2 x 10^7 cycles
Digital I/O Note: Digital Input: None, Digital Output :None
Electrical Output: N/A
Power Consumption: 2.9 W
Relative Humidity: 10 to 90% RH, non-condensing
Supply Power Note: Power Requirements: Reverse Polarity Protection: Yes
Data Interface Note: Modbus TCP, Modbus UDP;Ethernet Port: 10/100 base-TX with Auto MDI/ MDI-X;Watchdog: Dual: Yes, module (0.8 seconds), communication (programmable);Security: ID, Password and IP filter;Web HMI: Yes, I/O Pair Connection: Yes
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -30 °C
Number of Channels, Input: N/A
Voltage Measurement Range: N/A
Number of Channels, Output: Power Relay: 8
Operating Temperature, Max: 75 °C
Operating Temperature, Min: -25 °C
