OMEGA OME-WISE-7151 Web Based Intelligent PAC Controllers with Modbus and PoE (Digital, Digital: 16)

Width: 72 mm

Height: 35 mm

Length: 123 mm

Memory: EEPROM: 16KB

Mounting: DIN-Rail or Wall Mount

Software: Built in: OME-WISE Firmware

Isolation: 3750 Vrms, 2-Way

Input Type: Digital

Configuration: 16-bit, SRAM: 512 KB, Flash Memory: 512KB

Digital Input: Digital (Wet contact): Low

Output Signal: Digital

Data Interface: Ethernet

LED Indicators: PoE Power: PoE on, L1: System running, L2: Ethernet link/act, L3: Ethernet 10/100M speed

Supply Voltage: 12 to 48 Vdc

Analog I/O Note: Analog Input Note: Digital Input;Input Channels: 16;Input Type: Wet contact (sink, source);On Voltage Level: 10 to 50 Vdc ;Off Voltage Level: 4 Vdc maximum;Input Impedance: 10 kΩ;Counter Input;Maximum Count: 65535 (16 bits); Maximum Input Frequency: 50 Hz; Minimum Pulse Width: 10 ms;Overvoltage Protection: 70 Vdc

Impedance Input: 10 kΩ

Digital I/O Note: Input Channels: 16 Input Type: Wet contact (sink, source) On Voltage Level: 10 to 50 Vdc Off Voltage Level: 4 Vdc maximum Input Impedance: 10 kΩ

Electrical Output: N/A

Power Consumption: 3.9 W

Relative Humidity: 10 to 90% RH, non-condensing

Software Settings: • Rule Configuration Website: Access Web server on OME-WISE-7000 controllers to edit and upload logic rules through web browser • 36 IF-THEN-ELSE Logic Rules: 3 IF conditions with AND or OR operators; 3 THEN actions; 3 ELSE actions • 48 Internal Registers: Hold temporary variables and read/write data via MODBUS/TCP address • 12 Timers: Delay/timing functions • 12 Emails: Send email messages to pre-setemail receivers • 12 CGI Commands: Send pre-set CGI commands • 12 Recipes: Set up THEN/ELSE action groups • 8 P2P Remote Modules: Set up the connection information for the remote OME-WISE-7000 modules • Rule Configuration Website: Access Web server on OME-WISE-7000 controllers to edit and upload logic rules through web browser • MODBUS/TCP Protocol: Real time control and monitoring I/O channels and system status of controllers via SCADA software"

Input Voltage Note: Absolute Maximum Input Voltage: Power on: 50 Vdc, Power off 4 Vdc

Data Interface Note: Ethernet Port: 10/100 Base-TX and automatic MDI/MDI-X with PoE (Power over Ethernet);Watchdog: Single;Supported Operating System: MiniOS7;Web HMI: Yes, I/O Pair Connection: Yes

Storage Temperature, Max: 80 °C

Storage Temperature, Min: -30 °C

Number of Channels, Input: Digital: 16

Operating Temperature, Max: 75 °C

Operating Temperature, Min: -25 °C
